JD3250X

MOLDED CASE, THERMAL MAGNETIC, JD FRAME with Interchangeable Trip Units; 600 VAC AT 50/60 HZ, 250 AMPERE AT 40 DEG C, 3 POLE, INTERRUPTING RATING 65 KILOAMPERE AT 240 VAC, 35 KILOAMPERE AT 480 VAC, 18 KILOAMPERE AT 600 VAC, 10 KILOAMPERE AT 250 VDC (UL), 65 KILOAMPERE AT 240 VAC, 35 KILOAMPERE AT 380/415 VAC, 10 KILOAMPERE AT 250 VDC (IEC), With Standard Load Terminals Only, Weight 12.50 Lbs (5.7 kg), SIZE 4.125 INCH W X 4.063 INCH D X 10 INCH H, JD MODEL, APPLICABLE STANDARD IEC 157-1 Molded Case Circuit Breakers from Eaton / Cutler-Hammer
